Required Equipment
Required Equipment
To perform all of the steps in this tour, you must have the following equipment:
• Agilent 4294A Precision Impedance Analyzer (1 unit)
• 16047E Text Fixture for Lead Components (1 piece)
• DUT: Capacitor with lead wires having self-resonance frequency of 100 MHz or lower,
such as a 0.1 mF ceramic capacitor (1 piece)
Figure 2-1 Required Equipment
