84 Chapter 5
Setting Measurement Conditions
Selecting Sweep Parameter
Selecting Sweep Parameter
Step 1. Press the [Sweep] key.
Step 2. Press the
PARAMETER [ ] key.
Step 3. Select the desired sweep parameter
NOTE When selecting the oscillator level as a sweep parameter, follow the steps shown in
“Selecting Unit for Oscillator Level (Voltage or Current)” on page 106 to select sweeping
by voltage or current level.
When selecting the dc bias as a sweep parameter, proceed to the setting shown in “Setting
and Applying dc Bias” on page 107.
The sweep parameter that is currently selected appears in the key label
[ ] of the
PARAMETER [ ] key.
NOTE See “Using Time as Sweep Parameter (Zero Span Sweep)” on page 94 for the
measurement with time as a sweep parameter (zero span measurement).
The sweep parameter can be set to trace A and trace B in common. It is not necessary to
select an active trace or to verify the current selection before setting the parameter.
Sweep parameter Key stroke
Frequency
FREQ
Oscillator level (voltage or current) OSC LEVEL
dc bias DC BIAS
Softkey label Selected sweep parameter
PARAMETER [FREQ] Frequency
PARAMETER [OLEV] Oscillator level (voltage or current)
PARAMETER [DCB] dc bias
To Next Page
