Agilent Technologies 4294A User Manual

Appendix B 363
Key Definitions
Softkeys displayed by pressing the [Meas] key
B. Key Definitions
Softkeys displayed by pressing the [Meas] key
Table B-7 Measurement parameter (Measurement) menu (1/3)
Key operation: [Meas]
Softkey Function GPIB command
|Z| - q
|
Selects impedance absolute value and impedance phase as measurement
parameters. The 1st parameter on the softkey label (in this case, |Z|) is assigned
to trace A; the 2nd parameter (in this case, q), to trace B. (This system of trace
assignent is applicable to other measurement parameters.)
MEAS IMPH
R - X
|
Selects series resistance and reactance as measurement parameters. MEAS IRIM
Ls - Rs
|
Selects series inductance and series resistance as measurement parameters. MEAS LSR
Ls - Q
|
Selects series inductance and Q factor (quality factor) as measurement
parameters.
MEAS LSQ
Cs - Rs
|
Selects series capacitance and series resistance as measurement parameters. MEAS CSR
Cs - Q
|
Selects series capacitance and Q factor (quality factor) as measurement
parameters.
MEAS CSQ
Cs - D Selects series capacitance and dissipation factor as measurement parameters. MEAS CSD
more 1/3 Displays Table B-8, “Measurement parameter (Measurement) menu (2/3),” on
page 363.
(N/A)
Table B-8 Measurement parameter (Measurement) menu (2/3)
Key operation: [Meas] - more 1/3
Softkey Function GPIB command
|Y| - q
|
Selects admittance absolute value and admittance phase as measurement
parameters.
MEAS AMPH
G - B
|
Selects conductance and susceptance as measurement parameters. MEAS ARIM
Lp - G
|
Selects parallel inductance and conductance as measurement parameters. MEAS LPG
Lp - Q
|
Selects parallel inductance and Q factor (quality factor) as measurement
parameters.
MEAS LPQ
Cp - G
|
Selects parallel capacitance and conductance as measurement parameters. MEAS CPG
Cp - Q
|
Selects parallel capacitance and Q factor (quality factor) as measurement
parameters.
MEAS CPQ
Cp - D Selects parallel capacitance and dissipation factor as measurement parameters. MEAS CPD
more 2/3 Displays Table B-9, “Measurement parameter (Measurement) menu (3/3),” on
page 364.
(N/A)
