Agilent Technologies 4294A User Manual

364 Appendix B
Key Definitions
Softkeys displayed by pressing the [Meas] key
Table B-9 Measurement parameter (Measurement) menu (3/3)
Key operation: [Meas] - more 1/3 - more 2/3
Softkey Function GPIB command
COMPLEX Z-Y
|
Selects complex impedance (Z) and complex admittance (Y) as measurement
parameters. If these parameters are selected, the graph is displayed in the
complex plane or polar coordinates (selected using Table B-12, “Format
(Format) menu (2),” on page 365).
MEAS COMP
|Z| - Ls
|
Selects impedance absolute value and series inductance as measurement
parameters.
MEAS IMLS
|Z| - Cs
|
Selects impedance absolute value and series capacitance as measurement
parameters.
MEAS IMCS
|Z| - Lp
|
Selects impedance absolute value and parallel inductance as measurement
parameters.
MEAS IMLP
|Z| - Cp
|
Selects impedance absolute value and parallel capacitance as measurement
parameters.
MEAS IMCP
other Displays Table B-10, “Measurement parameter (Measurement) menu (other),”
on page 364.
(N/A)
more 3/3 Displays Table B-7, “Measurement parameter (Measurement) menu (1/3),” on
page 363.
(N/A)
Table B-10 Measurement parameter (Measurement) menu (other)
Key operation: [Meas] - more 1/3 - more 2/3 - other
Softkey Function GPIB command
|Z| - Rs
|
Selects impedance absolute value and series resistance as measurement
parameters.
MEAS IMRS
|Z| - Q
|
Selects impedance absolute value and Q factor (quality factor) as measurement
parameters.
MEAS IMQ
|Z| - D
|
Selects impedance absolute value and dissipation factor as measurement
parameters.
MEAS IMD
Lp - Rp
|
Selects parallel inductance and parallel resistance as measurement parameters. MEAS LPR
Cp - Rp Selects parallel capacitance and parallel resistance as measurement parameters. MEAS CPR
return Returns to Table B-7, “Measurement parameter (Measurement) menu (1/3),” on
page 363.
(N/A)
