134 Chapter 6
Calibration
A. Calibration When Using Direct Connection Type Test Fixture
• 16089B Kelvin Clip Lead
• 16089C Kelvin Clip Lead
• 16089D Alligator Clip Lead
• 16089E Kelvin Clip Lead
Step 1. Make sure that the adapter selection is set to “No Adapter (
NONE).”
See “Adapter Setting” on page 67 for adapter selection.
Step 2. Perform the fixture compensation in accordance with “Fixture Compensation” on page
151.
NOTE When you use a direct connection type test fixture, neither user calibration nor port
extension compensation is required for measurement (they cannot be performed).
