Chapter 8 231
Analysis and Processing of Result
Search the maximum/minimum peak
8. Analysis and Processing
of Result
Figure 8-13 Search the left-hand peak after Figure 8-11 using the NEXT PEAK LEFT key
Step 5. Read the value displayed in the marker sweep parameter value area on the screen.
NOTE When the MAX, MIN, TARGET or PEAK key is used for searching, one search is carried out
for the trace when the key is pressed. If the search tracking function is on, search is
executed every time a sweep is completed.For details about the search tracking function,
refer to “Automatically performing search for each sweep (search tracking)” on page 235.
