Agilent Technologies 4294A User Manual

272 Chapter 8
Analysis and Processing of Result
Save and Recall the Agilent 4294A Internal Data
NOTE When using the floppy disk drive, make sure a disk is first inserted in the drive. If the
floppy disk is set to “Write Protect,” the data cannot be saved. Set the disk to “Write
Enable” before using it.
The storage device selection using
[System] - IBASIC - more 1/3 - MASS STORE [ ] is
applicable when using the storage devices of the Agilent
4294A through the HP
Instrument BASIC function. It is different from the storage device selection using the
STORE DEV [ ] key. However, the storage devices themselves are the same.
Step 4. Press the
return key to return to the Save menu. The selected storage device is displayed in
the box
[] of the key label of the STORE DEV [ ] key.
Step 5. Press the
STATE key. The file name input line to save the setting state, calibration data and
memory array appears in the upper left area of the screen, and the File Name Input menu is
displayed.
Step 6. Enter the file name in the character string input line by using a combination of the
following keys:
Non-volatile memory disk (flash memory) FLASH MEMORY
Softkey label Selected storage device
STORE DEV [FLOPPY] Floppy disk drive
STORE DEV [MEMORY] Volatile memory disk
STORE DEV [FLASH] Non-volatile memory disk (flash memory)
Key Function
Step keys ([][¯]) Scrolls the input character list indicated below
the character string line.
Rotary knob (
m
mm
m) Horizontally moves the cursor () located
below the displayed character list.
SELECT LETTER or [G/n] At the cursor (_) of the character input line,
enters the character specified by the cursor ()
below the character list.
Numeric keys (
[0] through [9], [.] and [-]) Enter the numerical value at the cursor (_) of
the character string input line.
SPACE Enters the space at the cursor (_) of the
character string input line.
BACK SPACE or [Back Space] Returns the cursor (_) of the character string
input line by one character to the left and
erases the character in that position.
CLEAR NAME Erases all the character strings entered in the
character string input line.
Storage device Key operation
