276 Chapter 8
Analysis and Processing of Result
Save and Recall the Agilent 4294A Internal Data
Table 8-5 Example of data saved in the text (ASCII) format
4294A REV1.01
"DATE: Nov 1 1999"
"MEASURE PARAMETER: IMPEDANCE MAG PHASE (DEG)"
"ADAPTER: NONE"
"SWEEP TYPE: LIN FREQ"
"NUMBER of POINTS: 201"
"POINT DELAY TIME: 0 Sec"
"SWEEP DELAY TIME: 0 Sec"
"OSC LEVEL: 500 mVolt"
"DC BIAS: OFF"
"BW: 1"
"SWEEP AVERAGING: OFF"
"POINT AVERAGING: OFF"
"Cal Point: FIXED"
"Frequency""Comp[open] Real""Comp[open] Imag""Comp[short] Real""Comp[short] Imag""Comp[load]
Real""Comp[load] Imag"
4.00000000000e+012.947073e-09-1.565653e-09-6.253917e-031.008368e-035.008568e+01-3.311127e-02
.....................................................................................................................................
.....................................................................................................................................
"TRACE: A"
"FORMAT: LOG"
"Frequency" "Data Real" "Data Imag" "Data Trace Real" "Data Trace Imag"
4.00000000000e+01 1.976390e-02 5.641327e-03 2.055326e-02 0.000000e+00
.....................................................................................................................................
.....................................................................................................................................
"TRACE: B"
"FORMAT: LINEAR"
"Frequency" "Data Real" "Data Imag" "Data Trace Real" "Data Trace Imag"
4.00000000000e+01 1.976390e-02 5.641327e-03 1.593065e+01 0.000000e+00
.....................................................................................................................................
.....................................................................................................................................
