Chapter 8 289
Analysis and Processing of Result
Save and Recall the Agilent 4294A Internal Data
8. Analysis and Processing
of Result
The setting of the storage device you select using [System] - IBASIC - more 1/3 -
MASS STORE [ ]
is applied when using the 4294A's storage devices from the HP
Instrument BASIC function, and it is different from the selection of the storage device
using the STORE DEV [ ] key here. However, the storage devices themselves are common.
Step 7. Press the
return key to return to the save menu. The selected storage device is displayed in
[] of the key label of the STORE DEV [ ] key.
Step 8. Press the
GRAPHICS key. The file name entry line to save the displayed screen appears
and the file name entry menu also appears.
Step 9. Use the following keys to enter a file name in the string entry line.
NOTE You do not need to add any extension to the file name.
Step 10. When you finish entering a file name in the string entry line, press the
done or [´1] key to
execute save. To cancel the save, press the
cancel key. In either case, you return to the save
menu .
NOTE You can use your external keyboard connected to the rear panel for Steps 6 and 7. After
entering a file name, press the
[Enter] key to execute save.
Table 8-22
Softkey label Selected storage device
STORE DEV [FLOPPY] Floppy disk drive
STORE DEV [MEMORY] Volatile memory disk
STORE DEV [FLASH] Nonvolatile memory disk (flash memory)
Key Function
Step keys ([][¯]) Scrolls the character entry list displayed below
the string entry line.
Rotary knob (m
mm
m) Moves the cursor () below the displayed
character list to right and left.
SELECT LETTER or [G/n] Enters the character specified with the cursor
() below the character list at the position of
the cursor (_) in the string entry line.
Numeric keys (
[0] through [9], [.], and [-]) Enters a numeric character at the position of
the cursor (_) in the string entry line.
SPACE Enters a white space character at the position
of the cursor (_) in the string entry line.
BACK SPACE or [Back Space] Returns the cursor (_) in the string entry line
one character left and deletes the character at
the position.
CLEAR NAME Deletes the whole of the string entered in the
string entry line.
