Agilent Technologies 4294A User Manual

372 Appendix B
Key Definitions
Softkeys displayed by pressing the [Display] key
PEN 4
|
Selects PEN 4
1
as the display item that can be changed with the MODIFY
COLOR key.
COLO PEN4
PEN 5
|
Selects PEN 5
1
as the display item that can be changed with the MODIFY
COLOR key.
COLO PEN5
PEN 6
Selects PEN 6
1
as the display item that can be changed with the MODIFY
COLOR key.
COLO PEN6
more 3/3 Displays Table B-23, “Item color modification (Color Item) menu (1/3),” on
page 370.
(N/A)
return Returns to Table B-22, “Display color modification (Modify Color) menu,” on
page 370.
(N/A)
1. These pens can be used to draw graphics by specifying them in HP Instrument BASIC programs.
Table B-26 Item color entry (Color Item) menu
Key operation: [Display] - more 1/2 - MODIFY COLOR - MODIFY ITEM COLOR
- MODIFY COLOR
[Display] - more 1/2 - MODIFY COLOR - MODIFY ITEM COLOR - more 1/3
- MODIFY COLOR
[Display] - more 1/2 - MODIFY COLOR - MODIFY ITEM COLOR - more 1/3
- more 2/3 - MODIFY COLOR
Softkey Function GPIB command
TINT
Adjusts tint
1
of the displayed items you have chosen from Table B-23, “Item
color modification (Color Item) menu (1/3),” on page 370, Table B-24, “Item
color modification (Color Item) menu (2/3),” on page 371, or Table B-25, “Item
color modification (Color Item) menu (3/3),” on page 371.
TINT <value>
BRIGHTNESS Adjusts color brightness of the displayed items you have chosen from Table
B-23, “Item color modification (Color Item) menu (1/3),” on page 370, Table
B-24, “Item color modification (Color Item) menu (2/3),” on page 371, or Table
B-25, “Item color modification (Color Item) menu (3/3),” on page 371.
CBRI <value>
COLOR
Adjusts chromaticity
2
of the displayed items you have chosen from Table B-23,
“Item color modification (Color Item) menu (1/3),” on page 370, Table B-24,
“Item color modification (Color Item) menu (2/3),” on page 371, or Table B-25,
“Item color modification (Color Item) menu (3/3),” on page 371.
COLOR <value>
RESET COLOR Returns the above 3 parameters for the displayed items you have chosen from
Table B-23, “Item color modification (Color Item) menu (1/3),” on page 370,
Table B-24, “Item color modification (Color Item) menu (2/3),” on page 371, or
Table B-25, “Item color modification (Color Item) menu (3/3),” on page 371 to
the factory states.
RSCO
return Returns to the higher-level menu that called this menu (Table B-23, “Item color
modification (Color Item) menu (1/3),” on page 370, Table B-24, “Item color
modification (Color Item) menu (2/3),” on page 371 or Table B-25, “Item color
modification (Color Item) menu (3/3),” on page 371).
(N/A)
1. Color continuity of the tint circle in which color changes from red, to green, to blue, to black, and back to red.
2. The degree of whiteness of color (from white to pure color).
Table B-25 Item color modification (Color Item) menu (3/3)
Key operation: [Display] - more 1/2 - MODIFY COLOR - MODIFY ITEM COLOR - more 1/3
- more 2/3
Softkey Function GPIB command
