52
FAX CALL ROUTINGCALL SERVER : TELEPHONE FEATURES
Ed. 04 3/4Réf. 3EH 21000 BSAA
ANALOG CONNECTION
Notas :
If the service is not active (no associated fax number), fax calls (with VOICE service) are put through to
the user station.
The call rings station XXX
Fax number
associated?
YES
NO
NO
YES
Incoming call from user XXX
Detection of fax
signals by DSP?
Call is routed to the
associated fax number
