Alcatel OmniPCX Office Technical Documentation

GENERAL DESCRIPTION PRODUCT PRESENTATION
Ed. 046/8 Réf. 3EH 21000 BSAA
BOARDS AND OPTIONS
Board Function Optional boards Connections
ATA2
ATA4
2 or 4 analog trunk line in-
terfaces
MET: pulse meter recei-
ver
Analog trunk line (TL),
TL-PS diversion
BRA2
BRA4
BRA8
2, 4 or 8 T0 basic accesses ISDN network
CPU, CPUe Processing Unit HSL1, HSL2: intercon-
nection with add-on
modules
XMEM: memory exten-
sion and/or IDE interfa-
ce for the hard disk
VoIP: Voice over IP for
e-XS model
AFU: auxiliary functions
Lanswitch or Ethernet
terminal
Please-wait message
player
Tuner for background
music
Alarm
Doorphone
Loudspeaker
General call ringer
Pulse metering device
PC PM5
CoCPU, CoCPU@ CoProcessing Unit VoIP: Voice over IP
SLANX: mini-switch
(CPU/CPUe - CoCPU/
CoCPU@ link)
WAN: additional Ether-
net link
Lanswitch or Ethernet
terminal
LanX8
LanX16
8 or 16 10/100 BT Ether-
net ports
@ Phones, Hub,
Lanswitch, PC, etc.
MEX (equipped
with an HSL1
board)
Add-on module controller
MIX244
MIX484
MIX448
MIX044
MIX084
MIX048
0, 2 or 4 T0 basic accesses
+ 4 or 8 UA interfaces
+ 4 or 8 Z interfaces
ISDN network, analog Z
terminals and Alcatel
Reflexes stations
PRA-T2
PRA-T1
DASS2
DLT2
PRA -T2, DASS2, DLT2: 30
B-channels + 1 D-channel;
2048 kbps)
PRA-T1: 23 B-channels + 1
D-channel; 1544 kbps
PRA-T2: ISDN network
DASS2: UK public/priva-
te network
DLT2: Private QSIG
network
PRA-T1: Hong-Kong
ISDN network

Alcatel OmniPCX Office Specifications

General

VoIP Support	Yes
SIP Support	Yes
ISDN Support	Yes
Analog Support	Yes
Integrated Voice Mail	Yes
Auto Attendant	Yes
Conferencing	Yes
VoIP Protocols	SIP, H.323
Power Supply	100-240 VAC, 50/60 Hz
Network Interfaces	10/100 Mbps Ethernet
Humidity	10% to 90% non-condensing
