BASE STATION COUNTERS
DESCRIPTION OF FIELDS
Board position:
To find the board's physical address from the counters' "board position", convert into decimal and apply
the following rule: board position/2 + 1 = physical address.
Example:
- For 00: 00/2 + 1 = 01 -> the board is in the first slot.
- For 02: 02/2 + 1 = 02 -> the board is in the second slot.
Device:
Base index in hexadecimal on the board.
nb = ((((d x 256) + c) x 256) + b) x 256) + a
nb = (b x 256) + a
Start address
given by
content of
p
ointer
DectBasCnt
Byte
nbr
Content
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
a
b
board position
device
nbr calls
nbr simult calls
nbr saturations
saturation time (ms)
nbr inter handovers
nbr intra handovers
position next board
device
a
a
a
a
a
b
b
b
c
d
b
b
a
b
nbr links lost
nb = (b x 256) + a
nb = (b x 256) + a
nb = (b x 256) + a
nb = (b x 256) + a
