INSTALLATION - CONFIGURATIONCALL SERVER : VOICE ON IP
Ed. 04 17/20Réf. 3EH 21000 BSAA
- Access the default router configuration menu, option 4. Enter the IP address of the default router
and confirm by pressing # (validation and return to previous menu). In our example:
• IP Enabler A: @IP RA = 192.168.90.1
• IP Enabler B: @IP RB = 192.168.75.1
- IP Enabler C: @IP RC = 192.168.122.10
- Access the TFTP server configuration menu, option 5. Press # to enter the IP address of the TFTP
server and confirm by pressing # (validation and return to previous menu). In our example:
• IP Enabler A: 192.168.90.110
• IP Enabler B: 192.168.90.110
- IP Enabler C: 192.168.90.110
- After configuring the 4 parameters, return to the main menu by pressing 0, then validate the con-
figuration by selecting 0 again in the main menu, the display will propose the confirmation screen
"Save modification":
• press " * " to cancel and restart the configuring procedure
- press " # " to save the parameters, the terminal will display the 2 screens "Modification saved"
and "IPPhone will reset" in turn before reinitializing itself:
Nota : The IP Enabler power supply must not be disconnected during this phase.
- On restarting the IP Enabler will perform 6 registration phases:
• Phase 1: IP initialization
• Phase 2: downloading of the configuration file
• Phase 3: downloading of the binary file
• Phase 4: flashing of the binary
• Phase 5: downloading of the starting file
- Phase 6: establishing of IP signaling
At the end of phase 6, the station is initialized and the terminal appears in the list of the PM5 stations.
Creation of the station is automatic, the system automatically assigns the first free directory number (it
is not necessary to create an IP terminal beforehand).
If an error occurs during the initialization sequence, a specific error message "Error x.yy" is displayed:
see "Maintenance" File.
