INSTALLATION - CONFIGURATION CALL SERVER : VOICE ON IP
Ed. 0416/20 Réf. 3EH 21000 BSAA
CONFIGURATION
An IP Enabler has a configuration interface that can be used to program the IP parameters to establish
the link with the PBX if necessary. The configuration menu is accessed by pressing the i and # keys in
succession, immediately after connecting the IP Enabler mains power adapter. The following com-
mands are used in the menus:
- #: validation and return to previous menu;
- 0: return to previous menu / exit;
- *: cancellation and return to previous menu;
- HP- and HP+ keys: previous screen / next screen (signaled by the symbols ` / ).
Access to the configuration menu is inhibited as soon as phase 5 of the initialization sequence begins.
Access the configuration menu by pressing the i then # keys in succession, immediately after connec-
ting the IP Enabler mains power adapter.
Main menu:
- 1. Mac Address: display of the MAC address of the IP Enabler (read only).
- 2. IP Parameters: display and modification of the IP parameters.
- 3. Versions: displays of the different software versions.
- 4. Others: display of the IP Enabler status.
Accessing the IP parameters menu: Option 2 - Parameters
- Press key 1 to switch from Dynamic mode to Static mode:
- Access the IP address configuration menu, option 2. Enter the IP address of the IP Enabler and con-
firm by pressing # (validation and return to previous menu) or quit by pressing *. E.g.
IP Enabler A: 192.168.90.100
IP Enabler B: 192.168.75.6
- IP Enabler C: 192.168.122.201
Nota : An address such as 192.168.75.6 will have to be entered as follows: 192 168 075006. To
confirm the data entry, press #, the display returns to the previous menu.
- Access the subnet mask configuration menu, option 3. Enter the subnet mask and confirm by pres-
sing # (validation and return to the previous menu). E.g.
IP Enabler A: 255.255.255.0
IP Enabler B: 255.255.255.0
- IP Enabler C: 255.255.255.0
1. MAC Addr es s 3. Ve
r
si ons
2. IP Parameters 4. Others
