CPU - CPUE BOARDSHARDWARE
Ed. 04 3/12Réf. 3EH 21000 BSAA
OUTPUT PORTS (BOARD STIFFENER)
Available functions:
- LAN: 10/100 base T Ethernet port (MDI-II/straight)
- AUDIO-OUT: loudspeaker, alarm and general bell interfaces; 12V output
- AUDIO-IN: please-wait message and background music interfaces
- DOORPHONE: doorphone interfaces
- CONFIG: RS232 for MMC, NMC and PPP connections
- MODULE1: HSL to add-on module 1
- MODULE2: HSL to add-on module 2
RJ45 pin 12345678
LAN outputs TX+ TX- RX+ RX-
AUDIO-OUT out-
puts
Audio
Out A
Audio
Out B
Alarm A CenRg
A
CenRg
B
Alarm B Ground +12 V
CONFIG outputs CTS DSR RX Ground Ground TX DTR RTS
MODULE1 out-
puts
TX+ TX- RX+ RX-
MODULE2 out-
puts
TX+ TX- RX+ RX-
AUDIO-IN outputs Audio In
A
Audio In
B
Audio
Ctrl A
Audio
Ctrl B
DOORPHONE
outputs
Door
PHB1
DoorPH
A1
DoorPH
A2
Door
PHB2
LAN AUDIO-OUT CONFIG
MODULE1 MODULE2 AUDIO-IN DOORPHONE
PROCESSING UNIT
LAN
FAN POWER
CPU
CPU
MODULE
WAN
WAN
LAN AUDIO-OUT CONFIG
MODULE1 MODULE2 AUDIO-IN DOORPHONE
PROCESSING UNIT
LAN FAN POWER
CPU
CPUe
MODULE
