CPU - CPUE BOARDS HARDWARE
Ed. 044/12 Réf. 3EH 21000 BSAA
MEANING OF THE LED INDICATIONS
Name Color Function
CPU Green CPU functioning LED (flashing)
POWER Red/Green - Mains operation: steady green LED
- Battery operation: steady yellow LED
- Idle: flashing red LED
FAN Red/Green - Both fans functioning: steady green LED
- 1 or both fans down: steady red LED
LAN Green LAN functioning LED (flashes when there is traffic)
MODULE Green Presence of HSL board
WAN Green Not Used
