ATA BOARDHARDWARE
Ed. 04 3/4Réf. 3EH 21000 BSAA
With TL forwarding
In the event of a power cut or CPU failure, this solution forwards the analog line connected to device
1 on the ATA board to another analog set in the system.
A
NALOG INTERFACES
SLI 1 6
PEB
PEA
Distribution panel
A
NALOG TRUNK ACCESS
A
TA4
Analog Public
Network
Analog
terminal
ZSETA
ZSETB
ZA, ZB
