File
19
DECTMMC STATION
Ed. 04 3/4Réf. 3EH 21000 BSAA
READING OF THE DATA CONCERNING MOBILES - HANDST
makes it possible to display the data (directory number, type of association with the system,
IPUI) relative to all the DECT mobiles declared in the system.
makes it possible to display the data of a specific mobile; enter the directory number of the mo-
bile whose data you wish to see.
BASE STATION FEATURES - BASES
Press and then enter the slot number and the equipment number of the interface to which
the base station to be parametered is connected.
makes it possible to modify the name of the base station.
makes it possible to display the status of the base station concerned. and make it
possible to put the base station concerned in or out of service.
displays the number of DECT channels (3 or 6) and gives access to the following sub-features
for the 4070 IO base station:
- : by successively pressing this key, indicate the connection distance from the base to the sys-
tem: short line (0-400 m), average line (400-800 m) or long line (800-1200 m). This data is ne-
cessary for synchronization with trame DECT.
- : by successively pressing this key, indicate whether the 2 antennas (Diversity) or only the first
(No diversity) are used.
- : reading the software version currently on the base station.
- : reading the software version for initialization of the base station.
makes it possible to delete the data relating to the base station concerned.
ACCESS PROCEDURE FOR A GAP DECT HANDSET - REGIST
makes it possible for a registered GAP DECT handset to carry out an access procedure. A
particular piece of information is sent to the DECT handset enabling it to carry out this procedure.
MANDATORY AUTHENTICATION CODE - AUTHEN
is used to define the system operating mode: recording of stations with or without an
authentication code. lets you switch from ON to OFF.
HAND
T
A
T
A
NAME
DETAIL
LENGTH
ANTDIV
B
TID
DEL
ET
A
A
THEN
A
CHOICE
