LANX BOARDHARDWARE
Ed. 04 3/4Réf. 3EH 21000 BSAA
CONFIGURATION EXAMPLE
PRO CESSI N G U N I T
SWI TCH
Alcatel
Por t 1
Por t 2
Por t 3
Por t 4
Up-Link
ETH ERN ET LAN SW I TCH
Se r ve r 1
Se r ve r 2
Ethernet 10/100 Mbits
Ethernet 10/100 Mbits
Ethernet 10/100 Mbits
Ethernet 10/100 Mbits
Ethernet 10/100 Mbits
Host 1
Host 2
Host 3
LAN X8
CPU
