File
5
SYSTEM MESSAGESMAINTENANCE
Ed. 04 13/24Réf. 3EH 21000 BSAA
120 MODULE BACK IN SERVICE Control-
ler board
(81 or 82)
INFO 0 = type of backpanel
board (4 = BACK1; 5 = BACK2;
6 = BACK 3
INFO 1 = module operating
mode (0 = restricted mode, run-
ning on battery; 1 = normal mo-
de, running on the mains)
121 MODULE REFUSED Control-
ler board
(81 or 82)
122 MODULE DISCONNECTED Control-
ler board
(81 or 82)
123 POWER SUPPLY FAULT CPU (80) INFO 0 = mains power state (0
= Mains KO - battery activated;
1 = mains OK)
124 FAN FAULT INFO 0 = module (0 = basic
module; 1 = extension 1; 2 =
extension 2)
INFO 1 = fan identity (0 = fan 1;
1 = fan 2)
INFO 2 = fan state (0 = KO; 1 =
OK
125 POWER SAVING
System in power saving mode ;
only the 2 first Reflexes sets and
the T0 access are taken account
INFO 0 = module (0 = basic
module; 1 = extension 1; 2 =
extension 2)
126 DSP RESOURCE KO
Message not processed by the
DSP of one of the controller
boards
CPU (80)
or con-
troller
board (81
or 82)
INFO 0 = 0 or 1 (DSP0 or DSP1)
127 DSP RESULT CODES
These codes are used in confir-
mation messages and by the re-
ception buffer
CPU (80)
or con-
troller
board (81
or 82)
INFO 0 = 0 or 1 (DSP0 or DSP1)
TYPE MESSAGE LOCA-
TION
ADDITIONAL INFORMATION ACTION
