Troubleshoot the Kinetix 5500 Drive System Chapter 7
This dialog box applies to Kinetix 5500 (EtherNet/IP network) servo drives.
Table 65 - Drive Behavior, FLT Sxx Fault Codes
Exception Fault Code Exception Text
Permanent
Magnet Motor
Induction Motor
Fault Action
Best Available
Stopping Action
(applies to major faults)
Ignore Alarm Minor Fault Major Fault
FLT S02 – MTR COMMUTATION Motor Commutation FaultX – –––XDisable/Coast
FLT S03 – MTR OVERSPEED FL
Motor Overspeed
Factory Limit Fault
X X –––XDisable/Coast
FLT S04 – MTR OVERSPEED UL
Motor Overspeed
User Limit Fault
X X XXXXDecel/Hold
FLT S05 – MTR OVERTEMP FL
Motor Overtemperature
Factory Limit Fault
X – –––XDisable/Coast
FLT S07 – MTR OVERLOAD FL
Motor Thermal Overload
Factory Limit Fault
X X –––XDecel/Disable
FLT S08 – MTR OVERLOAD UL
Motor Thermal OverLoad
User Limit Fault
X X XXXXDecel/Hold
FLT S10 – INV OVERCURRENT Inverter Overcurrent FaultX X –––XDisable/Coast
FLT S11 – INV OVERTEMP FL
Inverter Overtemperature
Factory Limit Fault
X X –––XDisable/Coast
FLT S13 – INV OVERLOAD FL
Inverter Thermal Overload
Factory Limit Fault
X X –––XDisable/Coast
FLT S14 – INV OVERLOAD UL
Inverter Thermal Overload
User Limit Fault
X X XXXXDecel/Hold
FLT S15 – CONV OVERCURRENT Converter Overcurrent FaultX X –––X Disable/Coast
FLT S16 – GROUND CURRENT
Ground Current
Factory Limit Fault
X X –––XDisable/Coast
FLT S18 – CONV OVERTEMP FL
Converter OverTemp
Factory Limit Fault
X X –––XDisable/Coast
FLT S20 – CONV OVERLOAD FL
Converter Thermal OverLoad
Factory Limit Fault
X X –––XDisable/Coast
FLT S21 – CONV OVERLOAD UL
Converter Thermal Overload
User Limit Fault
X X XXXXDecel/Hold
FLT S23 – AC PHASE LOSS AC Single Phase Loss FaultX X XXXXDecel/Disable
FLT S25 – PRECHARGE FAILURE Pre-charge Failure Fault X X –––XDisable/Coast
FLT S29 – BUS OVERLOAD FL
Bus Regulator Thermal
OverLoad
Factory Limit Fault
X X –––XDisable/Coast
FLT S30 – BUS OVERLOAD UL
Bus Regulator Thermal Overload
User Limit Fault
X X XXXXDecel/Hold
FLT S31 – BUS REG FAILURE Bus Regulator Failure X X –––XDisable/Coast
FLT S33 – BUS UNDERVOLT FL
Bus Undervoltage
Factory Limit Fault
X X –––XDecel/Disable
FLT S34 – BUS UNDERVOLT UL
Bus Undervoltage
User Limit Fault
X X XXXXDecel/Hold
FLT S35 – BUS OVERVOLT FL
Bus Overvoltage
Factory Limit Fault
X X –––XDisable/Coast
FLT S39 – BUS POWER LEAKAGE Bus Power Leakage Fault X X –––X Decel/Disable
FLT S45 – FDBK COMM FL
(1)
Motor Feedback Data Loss
Factory Limit Fault
X – –––XDisable/Coast
FLT S47 – FDBK DEVICE FAILURE Feedback Device Failure X – –––X Disable/Coast
FLT S49 – BRAKE SLIP FLT Brake Slip Exception X – XXXXDecel/Hold
FLT S50 – POS HW OTRAVEL Hardware Overtravel - PositiveX X XXXXDecel/Hold
