Plan the Kinetix 5500 Drive System Installation Chapter 2
Standalone Drive Systems
Shared DC (common-bus) Drive Systems
Shared AC Drive Systems
Table 9 - Input Power UL Circuit-protection Specifications
Kinetix 5500 Drives UL Applications IEC (non-UL) Applications
Drive Cat. No. Drive Voltage, nom Phase
Bussmann Fuses
Cat. No.
Molded Case CB
Cat. No.
DIN gG Fuses
Amps (max)
Molded Case CB
Cat. No.
2198-H003-ERSx
240V Single-phase KTK-R-2 140U-D6D2-B10 2 140U-D6D2-B10
240/480V Three-phase KTK-R-3 140U-D6D3-B20 4 140U-D6D3-B20
2198-H008-ERSx
240V Single-phase KTK-R-5 140U-D6D2-B20 6 140U-D6D2-B20
240/480V Three-phase KTK-R-7 140U-D6D3-B60 6 140U-D6D3-B60
2198-H015-ERSx
240V Single-phase KTK-R-10 140U-D6D2-B80 10 140U-D6D2-B80
240/480V Three-phase KTK-R-15 140U-D6D3-C12 16 140U-D6D3-C12
2198-H025-ERSx 240/480V Three-phase KTK-R-20 140U-D6D3-C20 20 140U-D6D3-C20
2198-H040-ERSx 240/480V Three-phase KTK-R-25 140U-D6D3-C25 25 140U-D6D3-C25
2198-H070-ERSx 240/480V Three-phase LPJ-35SP 140G-G6C3-C40 35 140G-G6C3-C40
Kinetix 5500 Drives
Cat. No.
Drive Voltage,
(three-phase)
nom
UL Applications IEC (non-UL) Applications
Bussmann Fuses
Cat. No.
Molded Case CB
Cat. No.
DIN gG Fuses
Amps (max)
Molded Case CB
Cat. No.
2198-H003-ERSx 240/480V KTK-R-10 140U-D6D3-C15 10 140U-D6D3-C15
2198-H008-ERSx 240/480V KTK-R-10 140U-D6D3-C15 10 140U-D6D3-C15
2198-H015-ERSx 240/480V KTK-R-15 140U-D6D3-C15 16 140U-D6D3-C15
2198-H025-ERSx 240/480V KTK-R-20 140U-D6D3-C20 20 140U-D6D3-C20
2198-H040-ERSx 240/480V KTK-R-25 140U-D6D3-C25 25 140U-D6D3-C25
2198-H070-ERSx 240/480V LPJ-35SP 140G-G6C3-C40 35 140G-G6C3-C40
Kinetix 5500 Drives
Cat. No.
Drive Voltage,
(three-phase)
nom
Bussmann Fuses
Cat. No.
Molded Case CB
Cat. No.
2 Axes 3 Axes 4 Axes 5 Axes 2 Axes 3 Axes 4 Axes 5 Axes
2198-H003-ERSx 240/480V KTK-R-15 140U-D6D3-C15
2198-H008-ERSx 240/480V KTK-R-15 140U-D6D3-C15
2198-H015-ERSx 240/480V KTK-R-20 KTK-R-25 – 140U-D6D3-C15 140U-D6D3-C20 –
2198-H025-ERSx 240/480V KTK-R-30 – 140U-D6D3-C25 140U-D6D3-C30 –
2198-H040-ERSx 240/480V LPJ-35SP LPJ-45SP – 140G-G6C3-C40 140G-G6C3-C50 –
2198-H070-ERSx 240/480V LPJ-60SP – 140G-G6C3-C60 –
