36 Rockwell Automation Publication 2198-UM001I-EN-P - May 2019
Chapter 2 Plan the Kinetix 5500 Drive System Installation
Table 10 - Input Power IEC (non-UL) Circuit-protection Specifications
Shared AC/DC and Hybrid Systems
Table 11 - Input Power UL Circuit-protection Specifications
Table 12 - Input Power IEC (non-UL) Circuit-protection Specifications
Kinetix 5500 Drives
Cat. No.
Drive Voltage,
(three-phase)
nom
DIN gG Fuses
Amps (max)
Molded Case CB
Cat. No.
2 Axes 3 Axes 4 Axes 5 Axes 2 Axes 3 Axes 4 Axes 5 Axes
2198-H003-ERSx 240/480V 16 140U-D6D3-C15
2198-H008-ERSx 240/480V 16 140U-D6D3-C15
2198-H015-ERSx 240/480V 20 25 – 140U-D6D3-C15 140U-D6D3-C20 –
2198-H025-ERSx 240/480V 32 – 140U-D6D3-C25 140U-D6D3-C30 –
2198-H040-ERSx 240/480V 35 50 140G-G6C3-C40 140G-G6C3-C50 –
2198-H070-ERSx 240/480V 63 – 140G-G6C3-C60 –
Kinetix 5500
Drives Cat. No.
Drive Voltage,
(three-phase)
nom
Bussmann Fuse
Cat. No.
Molded Case CB
Cat. No.
2 Axes 3 Axes 4 Axes 5 Axes 6 Axes 7 Axes 8 Axes 2 Axes 3 Axes 4 Axes 5 Axes 6 Axes 7 Axes 8 Axes
2198-H003-ERSx 240/480V KTK-R-10 KTK-R-15 140U-D6D3-C15
2198-H008-ERSx 240/480V KTK-R-15 KTK-R-20 140U-D6D3-C15
140U-D6D3-C20
2198-H015-ERSx 240/480V KTK-R-20 – 140U-D6D3-C15 140U-D6D3-C20 –
2198-H025-ERSx 240/480V KTK-R-30 – 140U-D6D3-C20 140U-D6D3-C30 –
2198-H040-ERSx 240/480V KTK-R-30 LPJ-45SP LPJ-50SP – 140U-D6D3-C30 140G-G6C3-C50 –
2198-H070-ERSx 240/480V LPJ-50SP – 140G-G6C3-C50 –
Kinetix 5500
Drives Cat. No.
Drive Voltage,
(three-phase)
nom
DIN gG Fuses
Amps (max)
Molded Case CB
Cat. No.
2 Axes 3 Axes 4 Axes 5 Axes 6 Axes 7 Axes 8 Axes 2 Axes 3 Axes 4 Axes 5 Axes 6 Axes 7 Axes 8 Axes
2198-H003-ERSx 240/480V 10 16 140U-D6D3-C15
2198-H008-ERSx 240/480V 16 20 140U-D6D3-C15 140U-D6D3-C20
2198-H015-ERSx 240/480V 20 – 140U-D6D3-C15 140U-D6D3-C20 –
2198-H025-ERSx 240/480V 32 – 140U-D6D3-C20 140U-D6D3-C30 –
2198-H040-ERSx 240/480V 32 50 – 140U-D6D3-C30 140G-G6C3-C50 –
2198-H070-ERSx 240/480V 50 – 140G-G6C3-C50 –
