3.3 Measuring Multichannel Optical Module Bit Error Rate
3-11
3
Measurement Examples
Figure 3.3-1 Simultaneously Measuring Bit Error Rate for 4 Channels
(MP2110A-014)
Optical Power
Programmable
Optical Fiber
Optical Coupler
or Optical Switch
TX1 to TX4
Data and
Data
�
�
�
�
�
�
�
RX1 to RX4
Data and
Data
�
�
�
�
�
�
�
DUT
Reference
Clock
