The following message dialogs are displayed when analysis errors occur.
Table 6.9.3-1 Jitter Analysis Error Message
Message Description
Illegal Error An unexpected error has occurred.
NRZ? NRZ? error has occurred in Scope.
Change settings of Scope so that NRZ? error will not
occur.
Pattern Lost The set pattern length does not meet the actual
pattern length. Set Pattern Length of Scope correctly.
TIE Error* The jitter has exceeded 1 UI.
Time Out Data cannot be acquired from Scope.
Confirm that waveform displays in Scope.
*: Time Interval Error
