7.1 Performance Test for Pulse Pattern Generator
7-11
7
Performance Test
Figure 7.1.4-3 Measurement Example of Skew
For PPG2 to PPG4, perform a test in the same way. For PPG3 and PPG4
test, change the Clock Output in step 4 to the following value.
Item Setting Value
Clock Output Ch3/4
