Appendix A Specifications
A-28
Table A.3.10-2 Optical Channel Performance (Cont’d)
Item Specifications
Optical Noise
When MP2110A-022, 023, 025, 026, 032, 033, 035, 036, or 039 is installed:
Conditions
When MP2110A-054
is not installed
When MP2110A-054
is installed*
2
SMF Input, 1310 nm,
OTU4 Filter
Typ. 3.4 µWrms,
Max. 4.3 µWrms
Typ. 4.8 µWrms,
Max. 6.1 µWrms
SMF Input, 1310 nm,
No Filter
Typ.5.4 µWrms
Max. 7.5 µWrms
Typ. 7.6 µWrms
Max. 10.6 µWrms
MMF Input, 850 nm,
OTU4 Filter
Typ. 6.7 µWrms
Max. 8.4 µWrms
Typ. 9.5 µWrms
Max. 11.9 µWrms
MMF Input, 850 nm,
No Filter
Typ. 8.1 µWrms
Max. 10.5 µWrms
Typ. 11.4 µWrms
Max. 14.9 µWrms
When MP2110A-030 is installed:
Conditions
When MP2110A-054
is not installed
When MP2110A-054
is installed*
2
SMF Input, 1310 nm,
OTU4 Filter
Typ. 4.8 µWrms,
Max. 6.1 µWrms
Typ. 6.8 µWrms,
Max. 8.6 µWrms
SMF Input, 1310 nm,
No Filter
Typ.7.6 µWrms
Max. 10.6 µWrms
Typ. 10.8 µWrms
Max. 15.0 µWrms
When MP2110A-040 is installed:
Conditions
When MP2110A-054
is not installed
When MP2110A-054
is installed*
2
SMF Input, 1310 nm,
OTU4 Filter
Typ. 5.8 µWrms,
Max. 7.3 µWrms
Typ. 8.2 µWrms,
Max. 10.4 µWrms
SMF Input, 1310 nm,
No Filter
Typ.7.8 µWrms
Max. 10.6 µWrms
Typ. 11.0 µWrms
Max. 15.0 µWrms
When MP2110A-042, 043, 045, 046, or 049 is installed:
Conditions
When MP2110A-054
is not installed
When MP2110A-054
is installed*
2
SMF Input, 1310 nm,
OTU4 Filter
Typ. 4.1 µWrms,
Max. 5.2 µWrms
Typ. 5.8 µWrms,
Max. 7.4 µWrms
SMF Input, 1310 nm,
No Filter
Typ.5.5 µWrms
Max. 7.5 µWrms
Typ. 7.8 µWrms
Max. 10.6 µWrms
MMF Input, 850 nm,
OTU4 Filter
Typ. 7.0 µWrms
Max. 8.9 µWrms
Typ. 9.9 µWrms
Max. 12.6 µWrms
MMF Input, 850 nm,
No Filter
Typ. 8.6 µWrms
Max. 11.1 µWrms
Typ. 12.1 µWrms
Max. 15.7 µWrms
*2: When the MP2110A-054 is installed, the specification values apply
only to Channel B. To other channels, the specification values at
“When MP2110A-054 is not installed” always apply.
