Appendix B Initial Values
B-4
Table B.3-2 Setup Dialog Box
Item Initial Value
General
Sampling
Sampling Type NRZ
Sampling Mode Eye
Test Pattern Variable
Number of Samples 2048
Accumulation Type Persistency
Limit Type Time
Time 10.0 sec
Samples 10 million
Waveforms 100 wfms
Averaging 10 wfms
Pattern 10 patterns
Utilities
Color
Waveform Gray Scale
Mask Purple
Display Information
Preset Information On
Label (None)
Warning
Overload On
Questionable Eye On
Save
Screen Copy
EYE/Pulse Shot Capture
Inverse Background Color Off
Waveforms Only Off
Pattern Capture
Samples / UI 32
