B.3 Scope
B-5
A
ppendix B
Table B.3-3 Measure Dialog Box
Item Initial Value
Amplitude/Time
Display On
Equalizer*
1
Display Equalized Waveform On
Equalizer Type TDECQ
Optimization Auto
Number of Precursors 2
Tap Count 5
Tap
1 0.000000
2 0.000000
3 1.000000
4 0.000000
5 0.000000
6 0.000000
7 0.000000
8 0.000000
9 0.000000
10 0.000000
11 0.000000
12 0.000000
13 0.000000
Mask Test
Mask Test Off
Eye Mask Select N/A
Test Method One Shot
Margin Type Hit Count
Hit Count 1 samples
Hit Ratio 5.0E–05
Mask Margin 0.0%
Align Method Zero/One/Crossing
Align Marker Display Off
X1 0.50 UI

X 1.00 UI
Y1
*2

Y
*2
Mask Area Restriction Off
Angle

0 degrees
Width

0.10 UI
*1: When MP2110A-095 is installed.
*2: Initial value is not defined.
