Appendix B Initial Values
B-6
Table B.3-4 Setup (NRZ Amplitude/Time) Dialog Box
Item Initial Value
Time
Rise/Fall Time 20/80%
Rise/Fall Time Correction Off
Correction Factor 0.0 ps
Eye Boundary
Offset form Crossing 0.50 UI
Width 0.20 UI
SNR Definition
Noise Measure Area Zero Level + One Level
Table B.3-5 Setup (PAM4 Amplitude/Time) Dialog Box*
Item Initial Value
Configuration
Sample Timing Track to Middle Eye
Timing
Eye Center Type Maximum Eye Width
Peak Power Hit Ratio 1.00%
EYE Height/Widths
Eye Opening Definition Zero Hits
Linearity Definition IEEE Clause 94
TDECQ
Target SER IEEE
(mantissa) 4.80
(exponent) E-04
Optimize Threshold On
*: When MP2110A-095 is installed.
