Appendix B Initial Values
B-8
Table B.3-7 Amplitude Dialog Box
Item Initial Value
Scale Offset
Scale 100 mV/Div*
1
(None)*
2
Offset 0 mV*
1
0

W*
2
Attenuation 0 dB
Tracking*
3
Off
Channel Math*
4
Off
Define Function CH A+CH B
Scale *
5
Offset 0 mV
O/E*
2
Input Connector (Wavelength) MMF 850nm*
6
SMF 1550nm*
7
Conversion Gain *
8
Responsivity *
8
Input Power –7.00 dBm
Filter Selection No Filter
Extinction Ratio Correction Off
Extinction Ratio Correction Factor 0.00%
*1: For electrical interface
*2: For optical interface
*3: Excluding MP2110A-023, MP2110A-025, MP2110A-026,
MP2110A-033, MP2110A-035, MP2110A-036, MP2110A-043,
MP2110A-045 and MP2110A-046
*4: For MP2110A-021
*5: Initial value is not defined.
*6: For MP2110A-026, MP2110A-036, MP2110A-039, MP2110A-046, and
MP2110A-049
*7: For MP2110A-022, MP2110A-023, MP2110A-025, MP2110A-030,
MP2110A-032, MP2110A-033, MP2110A-035, MP2110A-040,
MP2110A-042, MP2110A-043, 4and MP2110A-045
*8: This value has been set at the factory to achieve Input Connector
(Wavelength) default wavelength.
