B.3 Scope
B-9
ppendix B
Table B.3-8 Time Dialog Box
Item Initial Value
Rate
Data Clock Rate
Tracking Off
Tracking Target 26G
Recalculate Option Clock Rate
Clock Rate 6 445 313 kHz
Divide Ratio 4
Symbol Rate 25 781 250 kbaud
Divide Ratio Detect On
Precision Trigger*
1
Off
Scale/Offset
Unit UI
UI On Screen 2 UI
Offset*
2
0.00 UI
Pattern Length
Tracking Off
Master PPG1
Length 511 symbols
Software Delay
Channel A 0.0 ps
Channel B 0.0 ps
Channel C 0.0 ps
Channel D 0.0 ps
CRU or CRU(26G)*
3
Operation Mode Off
Clock Recovery
Operation Rate Variable
(Rate) 25 781 250 kbaud
CRU Loop BW 10 MHz
CRU or CRU(53G)*
4
Operation Mode Off
Clock Recovery
Operation Rate Variable (51.0-58.0Gbaud)
(Rate) 53 125 000 kbaud
CRU Loop BW 4 MHz
Auto Relock Off
*1: When MP2110A-024 is installed.
*2: When Sampling Mode is set to Pulse.
*3: When MP2110A-054 is installed.
*4: When MP2110A-055 is installed.
