2.2 Part Names
2-9
2
The following label is on the panel of MP2110A-030, MP2110A-032,
MP2110A-033, MP2110A-035, MP2110A-036, and MP2110A-039.
The following tables describe the panel.
Table 2.2.1-4 Lamp List
Name Description
Lights when MP2110A can receive remote commands upon
successful start. The color indicates the trigger clock input
status.
Green: The trigger clock is detected.
Red: The trigger clock is not detected. Check that the
signal is input to the trigger clock input
connector.
Orange: The trigger clock signal input is detected but is
out of the frequency range.*
Lights in red when a hardware fault is detected at startup.
The lamp may light in short time when turning on and off
the power, but this is not an error.
*: Check the following items when the Status lamp is lit in orange.
Refer to Section 6.2.6, “Time, CRU Dialog Box”, for the operation
method.
•
Specify the input trigger clock in the range from 0.1 to 15.0 GHz.
(When
ON is specified at Precision Trigger, specify 2.4 GHz or
more.)
•
When
Off is specified at Tracking in Time dialog box, match the
Clock Rate setting value and the actual trigger clock frequency by
one of the following methods.
•
Change the Clock Rate setting value to the actual trigger clock
frequency.
•
Execute Acquire Clock Rate.
•
When
PPG is specified at Tracking in Time dialog box, specify the
trigger clock frequency within the range defined by PPG's Bit Rate
and Divide Ratio.
•
When
CRU is specified at Tracking in Time dialog box, check CRU
In input signal and CRU setting in Time dialog box to turn Lock
Status green.
