2.5 Normal Measurement
HA-8190V 2-21
When preparing sample cups with sample:
Use the whole blood pair rack (WBlood PAIR) or hemolysis pair rack (HEMOL. PAIR).
a Set sample tubes with barcode labels in the odd-numbered ports.
b Set sample cups with sample in the even-numbered ports.
Example: The barcode of port 1 is assigned to the sample in
port 2.
4 Load the sample racks onto the sampler.
a Fit the recess at the side of the rack into the guide inside the rack
loading side.
Sample tube with barcode label
Sample cup with sample
12345678910
NOTE:
Do not set whole blood samples in the even-numbered ports of the hemolysis pair rack to avoid seriously
degrading the column. If whole blood is measured in these ports, it is recommended to replace the column with
a new one.
NOTE:
Load sample racks onto the sampler so that they do not fall over. Spilled sample may damage the instrument.
Unloading side
Loading side
NOTE:
One-way transportation (initial setting):
Up to 5 sample racks can be loaded onto the loading side
of the sampler. See “One-way transportation” in “6.2.
Glossary” on page 6-12.
Loop transportation:
Five sample racks can be loaded onto each of the
loading and unloading sides of the sampler. Set the start
rack as the first rack to be measured on the loading side.
See “Loop transportation” in “6.2. Glossary” on page
6-13.
Additional sample racks can be loaded onto the sampler while measurement is in progress.
Do not add sample racks or push the racks by hand while the sampler is operating. Touching
racks during transportation may result in injury, damage to the piercing nozzle, or incorrect
reading of sample IDs and sample rack types.
To Next Page
