Chapter 2 Measurement
HA-8190V 2-12
2.3 Preparation for Measurement
2.3.1 Checking Liquid Waste and Consumables
1 Check liquid waste.
a When using an optional liquid waste bottle, discard liquid waste if it is remaining in the bottle. When using the
drainage system at your facilities, check that the drain tubes are connected properly.
2 Check eluents and hemolysis washing solution.
a Replace the eluent packs and hemolysis washing bottle if the reagents are running out.
• See “4.2.1. Replacing the Eluent Packs” on page 4-3.
• See “4.2.2. Replacing the Hemolysis Washing Solution Bottle” on page 4-7.
3 Check the printer paper.
a The printer paper is running out if two red lines appear on both edges of the paper. If red lines are visible, replace
the paper roll with a new one.
• See “4.2.3. Replacing the Printer Paper” on page 4-10.
2.3.2 Startup
Follow the instructions described below to start the instrument up. It will take at most 30 minutes from the time when
the power is turned on to complete warm-up and priming, and ready itself for measurement.
a Press the standby switch.
• The standby switch will light up orange when the power is turned
on. A few seconds later, it will turn green.
Discard liquid waste in accordance with local regulations for biohazardous waste.
NOTE:
Check that eluents A, B and CV and the hemolysis washing solution are all set before turning on the power.
REFERENCE:
If the main power switch on the rear panel is off, set it in the
“on” position before pressing the standby switch to turn on the
power.
