HA-8190V 1-5
1.1 Overview
1.1.3 Specifications
Product ADAMS A1c HA-8190V
Configuration Instrument, sampler (with sample tube spinning unit) and accessories
Measurement objects Whole blood or hemolysis sample
Column COLUMN UNIT 90
Reagents ELUENT 90A, ELUENT 90B, ELUENT 90CV (or ELUENT 90CV-S) and
HEMOLYSIS WASHING SOLUTION 90H
Measurement item Stable HbA1c and HbF
(HbS and HbC separation and HbE and HbD detection can be performed in the
Variant mode.)
Displayed range *1 HbA1c: 3 to 20%, 9 to 195 mmol/mol
HbF: 0.0 to 99.9%
Authenticated-compatibility
range *2
HbA1c: 4 to 16%, 20 to 151 mmol/mol
Measurement principle Reversed-phase cation exchange chromatography
Measurement wavelength 420 nm/500 nm (Dual-wavelength colorimetry)
Sample supply Sampler
Resolution 0.1% Ratio, 1 mmol/mol
Processing speed Variant mode: 58 seconds/test
Fast mode: 24 seconds/test
Sample consumption Approximately 8 L (Whole blood)
Required sample volume Sample tube: Minimum 10 mm above the bottom
Sample cup: 400 L or more
Sample container Sample tube: (Approximately 13/15 mm diameter) (75 to 100 mm length)
Sample cup: 500 L
Compatible rack type ARKRAY racks
Number of measurement
samples
One-way transportation (factory-set): Maximum 50 samples
Loop transportation: Maximum 100 samples
Column temperature Approximately 40°C
Warm-up time Maximum 30 minutes
Display Color LCD with touch panel
Printer For use with 58 mm width thermal printer paper
Memory capacity 900 measurement results (including calibration results)
External output Serial 1 port (Can be optionally used as an Ethernet port.)
Communication system RS-232C compliant
(Switchable between one-way and two-way communications.)
Transmission speed RS-232C: Selectable from 300, 600, 1200, 2400, 4800, 9600 and 19200 bps
Ethernet: 10BASE-T or 100BASE-T
(Depending on the setting of the connected device)
Operating environment Temperature: 10 - 30°C, Humidity: 20 - 80% RH (No condensation)
Measurement environment Temperature: 10 - 30°C, Humidity: 20 - 80% RH (No condensation)
Storage environment Temperature: 1 - 30°C, Humidity: 20 - 80% RH (No condensation)
Environment during transport Temperature: 1 - 60°C, Humidity: 20 - 80% RH (No condensation)
(The humidity should not exceed the absolute humidity; 40°C/85% RH.)
Dimensions 530 (W) 530 (D) 530 (H) mm
(Not including the hemolysis washing solution bottle)
Weight Main body: Approximately 41 kg, Sampler: Approximately 4 kg
Power input 100 - 240 V AC ± 10%, 50/60 Hz
Power consumption Maximum 300 VA
