THE I SERIES STANDARD CONTROL BOX V4.3
mode, in this mode, user can remove the teach pendant and the user external IO to control the robot.
The teach pendant enable switch is inside of the control box, as illustrated below.
Figure 8.36 Teach pendant enable switch
User can only push the switch when the teach pendant power off.
Teach pendant enable switch
