Azbil Corporation Maintenance and Troubleshooting
Model MGG10C/14C - MagneW FLEX+/PLUS+ Converter 5-7
<2-contact outputs>
Step
Screen
Procedure
(English) (Japanese)
1
> ST. OUT1 CLOSE
ST. OUT2 CLOSE
>1
CL
OSE
2 CLOSE
Enter MAINTENANCE MODE
(see page 4-24). Use the
or
key to cycle through screen
until “OUTPUT CHECK”
screen appears.
Touch the
key once to move
the cursor to “OFF”. Touch the
key to switch the OFF screen
to ON screen. Touch the
key
twice to move to the “OUTPUT
CHECK ST. OUT” screen.
2
>
S
T.
OU
T1
O
PE
N
S
T.
OU
T2 CL
OSE
> 1 CLOSE
2 CLOSE
Touch the key to move the
cursor at the status (OPEN/
CLOSE).
3
> ST. OUT1 OPEN
ST. OUT2 OPEN
> 1 OPEN
2 OPEN
Use the key to move the
cursor at the status (OPEN/
CLOSE).
4
> ST. OUT1 OPEN
ST. OUT2 OPEN
> 1 OPEN
2 OPEN
Touch the key to move the
cursor to “>”.
5
Use the
or key to move
the other screen.
Then the contact input and
output are back to the current
status (OPEN/CLOSE).
