Safety Azbil Corporation
iv Model MGG10C/14C - MagneW FLEX+/PLUS+ Converter
MagneW FLEX+/PLUS+ Electromagnetic Flowmeter
Documentation Supplement
1. Mains supply
The symbol for a.c. or d.c. on the name plate is as follows:
for a.c. power supply
for d.c. power supply
2. Fuse marking
The fuse cannot be replaced by the operator.
Fuse rating and electric characteristics are as follows:
Fuse rating: Voltage 250V
Current 3A
Manufacturer type: 239003 (LITTEL FUSE)
3. Grounding (Earthing)
Protective grounding (earthing) should be connected as shown in Operator's Manual.
The MagneW
FLEX+/PLUS+ has protective grounding (earthing) terminals in the terminal
box and on the external surface of its casing (see gure).
Remote models Integral models
An external switch or circuit-breaker must be installed near the MagneW
FLEX+/PLUS+
on the power line.
4. Equipment operation
Power line is connected to commercial power. The terminal cover
must not be opened when power is on.
To Next Page
