Azbil Corporation Using the display panel
Model MGG10C/14C - MagneW FLEX+/PLUS+ Converter 4-29
2- contact outputs
Range function
Built-in counter
function
Contact input
function
Contact output function
0: Single range A: Addition X: Not activated X: Not activated
E: High 1 and High 2 alarm or Low 1
and Low 2 alarm
1: Alarm output
4: Self-check result output
5: Empty detection function
6: High/low limit alarm
B: Addition with
preset
X: Not activated 3: Preset output
D: Alarm + Preset output
F: Preset + Self-check
G: Preset + Empty detection
H: Preset + High/low limit alarm
I: Self-check result + Empty detection
J: Self-check result + High/low limit
alarm
K: Empty detection + High/low limit
alarm
1: Automatic
switching dual range
A: Addition X: Not activated 2: Range switching output
7: Alarm + Range switching output
8:Self-check result + Range switching
output
9: Empty detection + Range switching
output
A: High/low limit alarm + Range
switching output
C: Range switching output + Self-check,
Empty detection
B: Addition with
preset
X: Not activated B: Range switching output + Preset
output
3: Normal/reverse
automatic switching
range
A: Addition X: Not activated 2: Range switching output
7: Alarm + Range switching output
8:Self-check result + Range switching
output
9: Empty detection + Range switching
output
A: High/low limit alarm + Range
switching output
C: Range switching output + Self-check,
Empty detection
B: Addition with
preset
X: Not activated B: Range switching output + Preset
output
C: Normal/
reverse
totalization
X: Not activated 2: Range switching output
7: Alarm + Range switching output
8:Self-check result + Range switching
output
9: Empty detection + Range switching
output
A: High/low limit alarm + Range
switching output
C: Range switching output + Self-check,
Empty detection
