Field Description
Autoconfiguration on
Bootup
Select whether the ISDN switch type (D channel detection for
switched line) is to be automatically identified.
The function is enabled with "1.
The function is enabled by default.
Result of Autoconfig-
uration
Shows the status of the ISDN Auto Config.
Automatic D-channel detection runs until a setting is found, or
until the ISDN protocol is selected manually under Port Usage.
This field cannot be edited. The result of automatic configuration
for the Port Usage and the ISDN Configuration Type is dis-
played.
Possible values:
• All possible values for the Port Usage and the ISDN Config-
uration Type.
• A#: Detection is still running.
Port Usage Only if Autoconfiguration on Bootup is disabled.
Select the protocol that you want to use for the ISDN port.
Possible values:
• ) : The ISDN connection is not used.
• 51+  5)!
ISDN Configuration
Type
Only if Autoconfiguration on Bootup is disabled and for Port
Usage = 51+  5)! is set.
Select the ISDN connection type.
Possible values:
•   '1+ (default value): Point-to-multipoint
connection
•   : Point-to-point ISDN access.
The menu Advanced Settings consists of the following fields:
Fields in the Advanced Settings menu.
