3.3.1.3 GUI Menus
The configuration options of your device are contained in the sub-menus, which are dis-
played in the navigation bar in the left-hand part of the window.
Note
Please note that not all devices have the full range of functions. Check the software of
your device on the corresponding product page under www.bintec-elmeg.com.
SNMP Browser
If you select the )' :7 option under View header, you will see an HTML view of
all internal system MIB tables and can modify the saved values. This view is only provided
for professional configuration and extended monitoring.
SNMP (Simple Network Management Protocol) is a protocol that allows access for config-
uring your device. All configuration parameters are stored in the MIB (Management Inform-
ation Base) in the form of MIB tables and MIB variables. You can read and modify these
directly via the SNMP browser.
Caution
This configuration method assumes an in-depth system knowledge of bintec devices!
3.3.2 SNMP shell
SNMP (Simple Network Management Protocol) is a protocol that defines how you can ac-
cess the configuration settings.
All configuration settings are stored in the MIB (Management Information Base) in the form
of MIB tables and MIB variables. You can access these directly from the SNMP shell via
SNMP commands. This type of configuration requires a detailed knowledge of our devices.
bintec elmeg GmbH
3 Access and configuration
bintec RS Series 51
