17.12 HotSpot Gateway
Important
The Hotspot Gateway must not be operated with IPv6 enabled, since IPv6 data traffic
is not registered by the Hotspot Gateway and, therefore, cannot be controlled.
The HotSpot Solution allows provision of public Internet accesses (using WLAN or wired
Ethernet). The solution is adapted to setup of smaller and larger Hotspot solutions for
cafes, hotels, companies, communal residences, campgrounds, etc.
The HotSpot Solution consists of a bintec elmegbintec elmeg gateway installed onsite
(with its own WLAN access point or additional connected WLAN device or wired LAN) and
of the Hotspot server, centrally located at a computing centre. The operator account is ad-
ministered on the server via an administration terminal (e.g., a hotel reception PC); this in-
cludes functions such as registration entry, generating tickets, statistical analysis, etc.
Login sequence at the Hotspot server
• When a new user connects with the Hotspot, he/she is automatically assigned an IP ad-
dress via DHCP.
• As soon as he attempts to access any Internet site with a browser, the user is redirected
to the home/login page.
• After the user has entered the registration data (user/password), these are sent to the
central RADIUS server (Hotspot server) as RADIUS registration.
• Following successful registration, the gateway opens Internet access.
• For each user, the gateway sends regular additional information to the RADIUS server
for recording accounting data.
• When the ticket expires, the user is automatically logged off and again redirected to the
home/login page.
Requirements
To operate a Hotspot, the customer requires:
• a bintec elmegbintec elmeg device as hotspot gateway with active Internet access and
configured hotspot server entries for login and accounting (see menu System Manage-
ment->Remote Authentication->RADIUS->New with Group Description $1
#+ )
bintec elmeg GmbH
17 Local Services
bintec RS Series 517
