Field Description
Possible values:
• 3% " : Your device automatically de-
termines the most favourable mode. It first tries all D channel
modes before switching to the B channel. (Costs are incurred
for using the B channel.)
• 3% 1( 5 61 ': Your device auto-
matically determines the most favourable D channel mode.
The use of the B channel is excluded.
• . +%$% 5 61 ': Your device tries to
transfer the IP address in the mode set in the Mode field.
• *( +%$% 5 61 'F $11 "%9  :
61: Your device tries to transfer the IP address in the
mode set in the Mode field. If this does not succeed, the IP
address is transferred in the B channel. (This incurs costs.)
• . 1( : 61 ': Your device transfers the IP
address in the B channel. This incurs costs.
D Channel Mode Only for Transfer Mode = . +%$% 5 61
' or *( +%$% 5 61 'F $11 "%9
 : 61
Select the D channel mode in which your device tries to transfer
the IP address.
Possible values:
• 006 (default value): The IP address is transferred in the "LLC
information elements" of the D channel.
• .:355A: The IP address is transferred in the subaddress "in-
formation elements" of the D channel.
• 006  .:355A: The IP address is transferred in both the
"LLC" and "subaddress information elements".
14.1.2 Phase-1 Profiles
A list of all configured tunnel profiles is displayed in the VPN->IPSec->Phase-1 Profiles
menu.
