BinTec RS353a - Qos Interfaces;Policies

Field Description
• 56 5%1 E1: Differentiated Services Code Point
according to RFC 3260 is used to signal the priority of IP
packets (indicated in decimal format).
• 56 @?%1 E1: Differentiated Services Code
Point according to RFC 3260 is used to signal the priority of
IP packets (indicated in hexadecimal format).
• *- :( E1: The TOS value is specified in binary
format, e.g. 00111111.
• *- 5%1 E1: The TOS value is specified in decimal
format, e.g. 63.
• *- @?%1 E1: The TOS value is specified in
hexadecimal format, e.g. 3F.
Set COS value
(802.1p/Layer 2)
In the header of the Ethernet packets filtered by the selected fil-
ter, you can here set/change the service class (Layer 2 priority).
Possible values are whole numbers between  and ,.
The default value is .
Interfaces Only for Class map = )7
When creating a new class plan, select the interfaces to which
you want to link the class plan. A class plan can be assigned to
multiple interfaces.
10.5.3 QoS Interfaces/Policies
In the Networking->QoS->QoS Interfaces/Policies menu, you set prioritisation of data.
Note
Data can only be prioritized in the outgoing direction.
Packets in the high-priority class always take priority over data with class IDs 1 - 254.
It is possible to assign or guarantee each queue and thus each data class a certain part of
the total bandwidth of the interface. In addition, you can optimise the transmission of voice
data (real time data).
Depending on the respective interface, a queue is created automatically for each class, but
