Field Description
sources per group.
The default value is .
IGMP State Limit Enter the maximum permitted total number of incoming queries
and messages per second.
The default value is , i.e. the number of IGMP status mes-
sages is not limited.
12.3 Forwarding
12.3.1 Forwarding
In this menu, you specify which multicast groups are always passed between the interfaces
of your device.
12.3.1.1 New
Choose the Newbutton to create forwarding rules for new multicast groups.
Fig. 123: Multicast->Forwarding->Forwarding->New
The Multicast->Forwarding->Forwarding->New menu consists of the following fields:
Fields in the Basic Parameters menu.
Field Description
All Multicast Groups Select whether all multicast groups, i.e. the complete multicast
address range 224.0.0.0/4, are to be forwarded from the defined
Source Interface to the defined Destination Interface. To do
bintec elmeg GmbH
12 Multicast
bintec RS Series 301
