LED Colour Status Information
LAN 5
(Link/Act)
green on WAN-Ethernet connection established.
green flashing Data via LAN 5 send / receive.
off No Ethernet connection.
LAN 5
(Speed)
green on The device is connected to the WAN at
1000 Mbits.
orange on The device is connected to the WAN at 100
Mbits.
off The device is connected to the WAN at 10
Mbits, or no Data transfer.
You can determine the status of the router in BRRP operation with the aid of the status
LED.
LED BRRP-Anzeige
LED CVolour Status Information
STATUS green flashing The device is functioning as a master router.
STATUS green Heartbeat (on
- on - off)
The device is functioning as a backup
router.
1.2.4 Scope of supply
Your device is supplied with the following parts:
bintec RS123 and bintec RS123w
Scope of supply bintec RS123 bintec RS123w
Cable sets/mains unit/ other
Ethernet cable (yellow)
ISDN cable (black)
Power cable
19" Mounting frame
Screws
Ethernet cable (yellow)
ISDN cable (black)
Power cable
19" Mounting frame
Screws
2 exteral WLAN antenna
Documentation
Safety notices
Installation poster
Safety notices
Installation poster
Online documentation
User's Guide User's Guide
