LED Colour Status Information
POWER green on Power supply is connected.
off No power supply.
STATUS green on After switching on: The device has started.
During operation: An error has occurred.
green flashing The device is active.
green off During operation: An error has occurred.
DSL
(RS353a,
RS353aw)
green on Connection established.
green slow flashing Synchronisation running.
off No Synchronisation.
SFP (RS123,
RS123w)
green flickering Data transfer.
off No connection.
flashing Data traffic via SFP interface.
WLAN
(RS123w,
RS353aw)
green on WLAN connection established.
green off Radio or all assigned VSS inactive
green on (slowly
flashing)
VSS is active, no client connected
green on (fast flash-
ing)
VSS is active, at least one client connected
USB green on (flickering) VSS is active, at least one client connected,
active data traffic
green flashing Data traffic via USB send / receive.
off No USB connection.
LAN 1 bis 4
(Link/Act)
green on Ethernet connection established.
green flashing Data traffic via Ethernet.
off No Ethernet connection.
LAN 1 bis 4
(Speed)
green on 1000 Mbits transfer rate.
orange on 100 Mbits transfer rate.
off 10 Mbits transfer rate.
