Fig. 67: Wireless LAN->WLAN->Client Link->
The Wireless LAN->WLAN->Client Link-> menu consists of the following fields:
Fields in the Basic Parameters menu.
Field Description
Network Name (SSID) Enter the name of the wireless network (SSID).
Enter an ASCII string with a maximum of 32 characters.
Fields in the Security Settings menu.
Field Description
Security Mode Select the security mode (encryption and authentication) for the
wireless network.
Possible values:
• % (default value): Neither encryption nor authentic-
ation
• 2 : WEP 40 bits
• 2 : WEP 104 bits
• 23 4 : WPA Preshared Key
Transmit Key Only for Security Mode = 2
Select one of the keys configured in WEP Key <1 - 4> as a de-
fault key.
The default value is 4( .
WEP Key 1 - 4 Only for Security Mode = 2 , 2
Enter the WEP key.
bintec elmeg GmbH
8 Wireless LAN
bintec RS Series 173
